Best Selling Sheet Metal Cut to Length Slitting Production Line

Overview

Basic Info.

Trademark	Raintech
Origin	China Shandong
HS Code	841900091
Production Capacity	20sets/Year

Product Description

Best Selling Sheet Metal Cut to Length Slitting Production Line

Cut to length line is used to unwind, level, cut the metal coil into the required length and stack it. It is suitable for cut-to-length cross-cutting operations for processing cold-rolled and hot-rolled carbon steel, silicon steel, tinplate, stainless steel and various metal materials after surface coating.This production line has provided multiple lines for the welded pipe industry, sheet distribution industry, automobile industry, environmental protection industry, and metal sheet industry, with mature and reliable technology.
MAIN COMPONENTS

COIL SKID	V- type, main body welded by steel plate
COIL CAR	Pit type, main body welded by steel plate
PAPER WINDER	Pneumatic expanded operated mandrel type.The paper winder will rewind the interleaving paper, as the strip is paid off.
UNCOILER WITH SNUBBER ROLL	Cantilever with four segments type
COIL OPENER	Telescopic and swing type
HI LEVELER	4-Hi, 15 rolls type
LOOP TABLE	Swing type
SIDE GUIDE	Vertical roll guide type
FEEDER ROLL WITH MEASURING ROLL AND PVC COATER	2+3 rolls type
SHEAR	Mechanical type
BELT CONVEYOR	Belt type
PILER ,LIFTER ,CONVEYOR CAR
HYDRAULIC UNIT	1 set
PNEUMATIC UNIT	Pneumatic source:by buyer
ELECTRICAL EQUIPMENT	Adjustment, manually, automatic operation mode. One key start-up, multi-machine synchronization. Speed adjustment. Line stop to cuts specified. Fault information display and diagnosis. Maintenance help. Emergency stop, fast stop Start alarm caution.

Raintech design and produce the coil cut to length line according to different requirements from our customers. Also we can make small and compact cut to length line is suitable for the baby coils which max. Thickness 2mm, and coil width less than 600mm. Specially used for small coils cut into short steel plates. The whole line only 16 meters length, take very small space at your workshop. It's the most economic and humane design.
SPECIFICATION

Model Parameter	Material Thicknes (mm)	Max.Coil Width (mm)	Cutting Accuracy (mm)	Max. Speed (m/min.)	Max.Cutting Frequency (spm)	Uncoiling Weight (Tons)
SCL-6*1600	1-6	800-1600	±0.5	40	40	25
SCL-6*1850	1-6	900-1850	±0.5	40	40	30
SCL-6*2000	1-6	900-2000	±0.5	40	40	30
SCL-8*1600	2-8	900-1600	±0.5	35	30	25
SCL-8*1850	2-8	900-1850	±0.5	35	30	30
SCL-8*2000	2-8	900-2000	±0.5	35	30	30
SCL-12*2000	3-12	900-2000	±1.5	30	15	35
SCL-16*2000	4-16	900-2000	±2.0	20	10	35
SCL-20*2000	8-20	900-2000	±2.0	20	10	35

After Sales Service

1. OEM Design&Production Our active engineer and design team can make the special machine according to customer's special requirements.2. Delivery in Time Assurance We assure the machines your ordered will delivered at promised time3. Free Installation&Training We provide the installation and training by online video support; local installation and training service team; send engineer for installation and training; installation operation video provided4. Your Payment Protection You can pay through Alibaba to protect your advance payment5. Online Factory Inspection Service The factory inspection before your order, will be provided online by video meeting app, like room, wechat,skype etc..6. Long Life Maintenance of Machine We keep provide the maintenance for all machine life7. International Third Party Inspection Supported You can appoint the international third party party, such as TUV, SGS,BV, do inspection before shipment

FAQ

1. Q: Are you a Manufacturer or a trading company? A:We are a professional manufacturer with more than 15 experience in manufacturing, assembling and selling in this field. We have our own factories as well as trading companies2. Q: How long have your factory been in this field? And how many staff do you have? A: We have been in this field mode than 12 years since the year of 2008, total staff more than 100.3. Q:Where are you and how can I visit you? A: Our factory located in Jinan City, Shandong Province China, contact us before your visit in order that we can arrange the good reception.4. Q: Can you provide a customized solutions? A: Yes, our engineers are pleased to listen your idea and customized design is available5. Q: What about the warranty? A: We provide 12 months warranty since the machine arrival. free charge of spare parts and regularly maintenance service.6. Q:How about the delivery time ? A: The delivery time is different on different products.We never receive any complain from our customers for the delivery time7. Q: What about the package and shipment , worry about damage in shipping . A:The machine will be packaged by multilayer plastic wrap for anti-humidity on the sea. The strong steel wire roops will be used for fix the machines in container to avoid any damage in transportation.8. Q: What kind of payment does your company support? A: T/T, 100% L/C at sight, Cash, Western Union are generally accepted.9. Q:Do u support on installation and training? A: Yes, we provide engineers to your site for installation and training, if conditions not allowed, we provide team work by video conference for installation gaudiness on line.
